Atomic 698 GT-A | Race Spec | 1000hp Capable

$19,999.00 AUD
$19,999.00 AUD
Sale Sold out
/
Tax included.
Car Model:
Rocker Cover Colour:
Satin Black
Matte Black Wrinkle
Gloss Black
Metallic Blue
Metallic Red
Metallic Orange
Metallic Purple
Metallic Silver
Metallic Gunmetal Grey
This is a pre order item. We will ship it when it comes in stock.
Description

The Atomic 698 GT-A is a  engineered, high-performance long engine designed for enthusiasts who demand the ultimate in power and reliability. Built upon a foundation of carefully selected and prepared components, the 698 GT-A delivers exceptional horsepower and torque while ensuring the durability needed for demanding applications.



Key Features:

  • Optimized Block:
    • Ultrasonic tested seasoned Ford block, chosen for maximum wall thickness and strength.
    • Deburred oil drainback holes, webbing, and coolant passages for enhanced flow.
  • Precision Crankshaft:
    • Stage 2 prepared crankshaft: crack tested before being polished and chamfered
  • High-Performance Pistons & Rods:
    • Cosworth F1 Series dish top pistons with 8.7:1 compression ratio and 4-valve reliefs.
    • Atomic billet Superleggera connecting rods with CA625 bolts as standard, cylindrically ground/honed tunnels, and pressure-fed gudgeons for optimal strength and cooling.
  • Enhanced Cylinder Head:
    • Fully prepped Atomic Stage 4 cylinder head with CNC machined valve job, hand porting, and streamlined injector boss tracts.
    • Stainless oversize valves, Ovate Race Spec springs, and H/D collet set for superior valve control.
  • Robust Valve Train & Timing:
    • Atomic anti pump-up lifters and preload settings optimized for high RPM.
    • Atomic billet camshafts (customer's choice of profile).
    • Atomic heavy-duty timing chain kit with billet steel crank sprocket and parabolic billet guide.
  • Strengthened Bottom End:
    • Atomic hi-tensile 10mm billet steel main cap girdle and windage tray for increased block rigidity.
    • ACL Competition bearings with 360-degree thrust bearings as standard
    • Hi-flowed #6 and #7 main bearings.
    • Atomic/ATI Super-Damper ANDRA/SFI approved harmonic balancer and hub assembly.
  • Oil System Enhancements:
    • Atomic ALL-STEEL Billet gear oil pump with EDM cut gears, billet steel end plate, and upgraded relief spring.
    • Race spec clearances throughout the engine to suit intended usage.
  • Precision Machining & Assembly:
    • Fully machined block: torque plate honed cylinders, decked to crank centerline, main saddle alignment checked.
    • Fine Ra finish on deck surface and chambers relieved.
    • Precision blueprinting and assembly of long motor.
  •  Tested Before Delivery:
    • Engine is fully test-run in our engine test cell with comprehensive report supplied.

Included:

  • New brass Welch plugs.
  • Engine paint (choice of color).
  • Powder coated rocker cover and timing cover (choice of hundreds of colors).
  • Torque specs manual, run-in procedure sheet, spare gaskets, merch.
  • 14 liters of run-in 15W/40 oil, Ford oil filter, and NGK spark plugs.
  • 12-month conditional warranty.

Optional Upgrades:

  • Part grout-filling of coolant passages.
  • Fire ring head gasket kit.
  • CNC drilled block and head to suit 14.3mm size head studs.
  • Atomic M14.3mm Tool Steel Head stud kit with O/S washers.
  • Adjustable vernier gear cam sprockets.
  • VTC Delete spigots and Blank-off plates.
  • Atomic Roller rockers.
  • Titanium valve spring retainers.
  • Torrington crank thrust bearing upgrade.
  • High volume Big Ears sump upgrade.
  • Dowelling of crank to flexplate/flywheel.
  • -10 AN welded in rocker cover breathers.
